Radial Form Engagement
The tool feeds radially into shafts or bore cavities to cut full-radius keyways and seal seats.
Mills / Keyseat cutters
Full Radius Keyseat Cutters
What Are Full Radius Keyseat Cutters and How Do They Work?
A full radius keyseat cutter is a form cutter for slots with rounded concave bottoms rather than sharp 90-degree corners. Its 180-degree convex peripheral profile distributes contact through a continuous curve and forms the groove radius in one radial cutting path.
Stress-Relieved Slotting
The convex profile removes sharp slot-root corners and reduces local stress concentration.
Precision Groove Formation
Peripheral teeth form parallel side walls and a centered concave bottom radius.
Reduced-Neck Clearance
The narrow neck clears adjacent shoulders during radial in-feed.
Key Features and Benefits of Full Radius Keyseat Cutters
Reduced Stress Concentration
Rounded internal corners distribute load more gradually than sharp slot roots in torsion-loaded parts.
Controlled Form Accuracy
Precision profile grinding supports repeatable radius geometry across production parts.
Smooth Surface Quality
High-rake peripheral teeth support clean slot walls and smooth groove bottoms.
Stable Radial Cutting
Rigid tool geometry helps limit vibration during deep side-milling passes.
Material Versatility
Available tool materials and coatings support alloy steel, stainless steel, titanium, brass, and engineering plastics.
Full Radius Keyseat Cutters Specifications
| Spécification | Plage / Détails |
|---|---|
| Cutter Diameter Range | 1/2" to 1-1/2"+; metric 12 mm to 40 mm+ available |
| Cutter Width (2 × Radius) | 1/16" to 3/8"+; full radius equals half the cutter width |
| Profile Form | 180° full convex radius geometry |
| Flute Count | 6 to 14+ peripheral teeth |
| Shank Style | Straight cylindrical or Weldon flat shank |
| Operation Type | Radial full-radius keyseat slotting, O-ring grooving, and fluid-channel milling |
Materials and Coatings Available for Full Radius Keyseat Cutters
| Matière / Revêtement | Idéal pour | Avantage clé |
|---|---|---|
| Solid Carbide | Stainless steel, titanium, hardened steels, and high-volume runs. | High stiffness limits deflection and supports controlled radius geometry. |
| HSS-Co (Cobalt) | Interrupted cuts, manual machines, and lower-volume job-shop work. | Shock toughness helps resist tooth chipping during demanding radial cuts. |
| TiAlN / AlTiN Coating | Tough alloy steels, cast iron, and high-heat dry milling. | Oxidation resistance helps protect peripheral teeth from friction wear. |
Solid carbide provides stiffness for production grooving, HSS-Co provides shock toughness for manual or interrupted cuts, and TiAlN or AlTiN supports high-heat ferrous machining.
Which Machines Use Full Radius Keyseat Cutters?
CNC Machining Centers
Run automated full-radius slotting and O-ring grooving cycles.
Live-Tooling CNC Lathes
Mill radial and axial full-radius keyways directly on turned shafts.
Precision Manual Mills
Produce custom round-bottom keyways in prototype and repair work.
Applications and Industries for Full Radius Keyseat Cutters
Stress-Relieved Keyseat Milling
Cuts round-bottomed keyways in high-torque drive shafts to reduce sharp-corner stress concentration.
O-Ring and Fluid-Seal Grooving
Machines round-bottomed internal and external O-ring channels for hydraulic fittings.
Oil and Fluid Distribution Slots
Cuts smooth, rounded oil-routing tracks along bearing journals and shaft sleeves.
High-Fatigue Fastener Retainers
Prepares rounded retaining-ring seats in aerospace actuator components.
Frequently Asked Questions About Full Radius Keyseat Cutters
What is the difference between standard and full-radius keyseat cutters?
A standard keyseat cutter uses a flat peripheral profile to cut a rectangular slot with sharp bottom corners. A full-radius cutter has a convex cutting profile that forms a smooth 180-degree concave slot bottom.
Why are full-radius keyseat cutters used for high-torque shafts?
Sharp internal corners can concentrate torsional stress and contribute to fatigue cracks. A full-radius groove distributes stress through a curve, reducing the slot-root concentration when specified by the component design.
Can a full radius keyseat cutter plunge axially?
No. These tools are non-center-cutting and are intended for radial in-feed and side milling. Position the cutter outside the workpiece or in a prepared clearance area before feeding radially.
How is the radius size specified?
The source defines the full radius as half the total cutter width. For example, a cutter with a 0.250" face width has a continuous 0.125" convex radius.
Does Bauron manufacture custom full radius keyseat cutters?
Bauron can review custom head diameters, face widths, neck-clearance lengths, and application-specific TiAlN coatings based on manufacturing drawings.
Ressource d'ingénierie partagée
Design and Engineering Support
Bauron provides design and engineering support for custom geometries, specialized coatings, and application-specific full-radius keyseat requirements.
